Component Ruggard Electronic Dry Cabinet Tempered Glass 540L

Component Ruggard Electronic Dry Cabinet Tempered Glass 540L

  • High Light

    540L Electronic Dry Cabinet

    ,

    870L Electronic Dry Cabinet

    ,

    540L electronic component storage cabinet

  • Product Name
    Electronic Component Storage Cabinet
  • Product Model
    FCM/FCD/FCDE
  • Manufacturer
    CNSMT
  • Structure
    2/4/6doors With The Different Qty Shelves
  • Application
    Inductry Factory, SMD Components
  • Material
    Steel.tempered Glass Dry Cabinet
  • Humidity Range
    1-60% Option
  • Voltage
    110v/220v
  • Lead Time
    3-5days
  • Place Of Origin
    Shenzhen,China
  • Weight
    50-100kg
  • Warranty
    1YEAR
  • Place of Origin
    China
  • Brand Name
    CNSMT
  • Certification
    CE- Dry cabinet
  • Model Number
    FCM/FCD/FCDE
  • Minimum Order Quantity
    1
  • Price
    500
  • Packaging Details
    Standard woodenbox
  • Delivery Time
    3-4days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    5perday

Component Ruggard Electronic Dry Cabinet Tempered Glass 540L


Component Ruggard Electronic Dry Cabinet Tempered Glass 540L



Electronic Component Dry Cabinet-CNSMT





Product Description


CNSMT is a high-tech enterprise integrating R&D, production and after-sales. The main products are moisture-proof cabinets, electronic moisture-proof cabinets, industrial moisture-proof cabinets, anti-static moisture-proof cabinets, nitrogen moisture-proof cabinets, moisture-proof cabinets, drying cabinets, etc.



CNSMT provides users with targeted professional comprehensive services, covering consulting services for one product and one parameter based on temperature and humidity storage.



The products serve the electronics industry, printing industry, chemical industry, communications industry, military industry and cultural and cultural industries.



Specification



FCM 160 20-60%RH 160 W448*D420*H910 W450*D450*H1010 110V/220V
FCM 240 20-60%RH 240 W598*D370*H1150 W600*D400*H1250 110V/220V
FCM 320 20-60%RH 320 W898*D420*H910 W900*D450*H1010 110V/220V
FCM 435 20-60%RH 435 W898*D570*H910 W900*D600*H1010 110V/220V
FCM 540 20-60%RH 540 W598*D720*H1385 W600*D750*H1485 110V/220V
FCM 728 20-60%RH 728 W598*D680*H1840 W600*D710*H1940 110V/220V
FCM 870 20-60%RH 870 W898*D570*H1800 W900*D600*H1900 110V/220V
FCM 1428A 20-60%RH 1428 W1198*D680*H1840 W1200*D710*H1940 110V/220V
FCM 1428B 20-60%RH 1428 W1198*D680*H1840 W1200*D710*H1940 110V/220V
FCDE 160 1-10%RH 160 W448*D420*H910 W450*D450*H1010 110V/220V
FCDE 240 1-10%RH 240 W598*D370*H1150 W600*D400*H1250 110V/220V
FCDE 320 1-10%RH 320 W898*D420*H910 W900*D450*H1010 110V/220V
FCDE 435 1-10%RH 435 W898*D570*H910 W900*D600*H1010 110V/220V
FCDE 540 1-10%RH 540 W598*D720*H1385 W600*D750*H1485 110V/220V
FCDE 728 1-10%RH 728 W598*D680*H1840 W600*D710*H1940 110V/220V
FCDE 870 1-10%RH 870 W898*D570*H1800 W900*D600*H1900 110V/220V
FCDE 1428A 1-10%RH 1428 W1198*D680*H1840 W1200*D710*H1940 110V/220V
FCDE 1428B 1-10%RH 1428 W1198*D680*H1840 W1200*D710*H1940 110V/220V
FCD 160 10-20%RH 160 W448*D420*H910 W450*D450*H1010 110V/220V
FCD 240 10-20%RH 240 W598*D370*H1150 W600*D400*H1250 110V/220V
FCD 320 10-20%RH 320 W898*D420*H910 W900*D450*H1010 110V/220V
FCD 435 10-20%RH 435 W898*D570*H910 W900*D600*H1010 110V/220V
FCD 540 10-20%RH 540 W598*D720*H1385 W600*D750*H1485 110V/220V
FCD 728 10-20%RH 728 W598*D680*H1840 W600*D710*H1940 110V/220V
FCD 870 10-20%RH 870 W898*D570*H1800 W900*D600*H1900 110V/220V
FCD 1428A 10-20%RH 1428 W1198*D680*H1840 W1200*D710*H1940 110V/220V
FCD 1428B 10-20%RH 1428 W1198*D680*H1840 W1200*D710*H1940 110V/220V
DG 160 1-60%RH 160 W448*D420*H910 W450*D450*H1010 110V/220V
DG 240 1-60%RH 240 W598*D370*H1150 W600*D400*H1250 110V/220V
DG 320 1-60%RH 320 W898*D420*H910 W900*D450*H1010 110V/220V
DG 435 1-60%RH 435 W898*D570*H910 W900*D600*H1010 110V/220V
DG 540 1-60%RH 540 W598*D720*H1385 W600*D750*H1485 110V/220V
DG 728 1-60%RH 728 W598*D680*H1840 W600*D710*H1940 110V/220V
DG 870 1-60%RH 870 W898*D570*H1800 W900*D600*H1900 110V/220V
DG 1428A 1-60%RH 1428 W1198*D680*H1840 W1200*D710*H1940 110V/220V
DG 1428B 1-60%RH 1428 W1198*D680*H1840 W1200*D710*H1940 110V/220V

Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 0



Feathers:


Use field:



This series of constant temperature and humidity storage cabinets can store most of the products on the market that are affected by the temperature and humidity of the external environment, such as aircraft specific maintenance precision parts instruments, film, optical and chemical precision instruments, high-quality wooden floors, medicine, photographic film, Cosmetics, car seals, electronic IC chips, museums, etc. And get the approval of some companies in these fields, and reach a long-term cooperation agreement.



---Moisture proof principle:



The main core dehumidification component of the moisture-proof cabinet is the dehumidification movement on the back. The movement is equipped with four upper and lower movable doors, which are connected by alloy memory springs. During regeneration, the movable page door fits closely with the inner panel of the module and opens to the outside.



Heat the desiccant inside the module to dry it. After the regeneration is completed, when entering the dehumidification phase, the module enters a low power consumption maintenance state, the alloy memory spring automatically contracts, and the movable page door is closed to the outside. The desiccant acts on the cabinet, thereby reducing the humidity in the cabinet.



Cabinet structure introduction:



1. The body of the moisture-proof cabinet is made of 1.2mm high-strength cold-rolled steel plate, welded by CNC blanking, bending, and shielded welding, and precision welded by high-frequency argon arc. The door is made of non-toxic magnetic rubber strips to ensure sealing;



2. The Electronic Component Dry Cabinet door frame adopts permanent magnetic sealing rubber tape to ensure the airtightness of the cabinet body. The cabinet door is equipped with toughened glass as an observation window, which is intuitive and clear;



3. The inner and outer surfaces of the moisture-proof cabinet are sprayed with anti-static paint, which is suitable for storing electronic component products; 4. Layers: Adjustable layer plates are used to facilitate customers to allocate the space inside the Electronic Component Dry Cabinet reasonably;



5. Casters: Four sets of casters, you can move the Electronic Component Dry Cabinet at will, and two of them have brakes;



6. The back of the Electronic Component Dry Cabinet is equipped with a dehumidification module, which is seamlessly installed to ensure the airtightness of the cabinet;



7. The LED controller can intuitively read the humidity and operation of the cabinet.

Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 1

Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 2Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 3Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 4Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 5Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 6Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 7Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 8Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 9Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 10Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 11

Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 12

About us:


Quality policy: Customer satisfaction is our eternal service tenet. Providing customers with "zero defect" moisture-proof cabinet products and satisfactory after-sales service is the unswerving goal of every employee of the company.



Innovation, integrity, quality, service, and win-win It is the business philosophy of Huayu Hyundai. Focusing on customers, quality first and first-class service are Huayu Hyundai's service direction. Meeting customer needs, exceeding customer expectations, and becoming the most reliable enterprise for customers is the pursuit goal of Huayu Hyundai.



Quality Commitment: The company adheres to the quality control concept of quality first and full participation, and has a complete quality management system. The company has passed ISO9001 quality system certification and obtained CE certification for its main products.


Corporate vision: employees can keep a history, and the company can benefit the society

Enterprise mission: focus on employees, create the best platform, maximize the potential of employees, enjoy the work process, and selflessly work



Management philosophy: only rewards, no punishments; advance things first, pay attention to details, simulation; self-analysis, mutual supervision



Business philosophy: develop energy-saving and environmentally friendly products to solve storage troubles for the world



Entrepreneurial spirit: people-oriented, seeking management and nothing; talent concept: morality first, capable people make good use



Working principle: Focus on customer needs, provide cost-effective products and services, and maximize customer value



Work style: See the truth in the details! Today's matter, today's end



Packing&delivery:


Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 13






Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 14





Packing & Delivery




Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 15

Certification



Component Ruggard Electronic Dry Cabinet Tempered Glass 540L 16

Company Information


CNSMT is the leading manufacturer and supplieir for SMT machines and Solution with over 10 years' experience in China. And we can also do OEM&ODM for SMT traders, we have vast of sources in SMT field,even you need used or new SMT equipments or other parts, we can help you get the best quality and competitive cost machines.

What we can do for you:



※ We have our own factory make SMT equipments and devices
※ We have a professional technich engineer team for produce machines

※ We can customize variety of SMT machines for you according your requirements

We buy and sell used and new SMT equipments all over the world

※ We provide you SMT full line machines and export to worldwide
※ Becoming the most reliable Chinese partner for you.



FAQ:


1. Are you factory?

Yes, we are factory supplier focus on humidity control for 14 years.



2. Can you email the catalog?

Yes, we can send you by email with whole catalog.



3. How to order online?

Confirm product (quantity, price, payment, shipping etc)---waiting for email ---confirm order---make initial payment---production finish---make balance payment---shipping
* click to learn about trade assurance


4. What about the payment way?
30% deposit, balance paid before delivery -- amount > USD5,000
100% deposit -- amount < USD5,000




5. What's the shipping way and timing?
We suggest to ship by sea to get cheapest rate, voyage date to America around 30~40 days, to Europe 25~30 days, to Asia and Austrilia 7~15 days. Click here to get exact timing.


6. What's the warranty item?
Warranty time normally is 12 months, if you want to extend the warranty time to 24 months, the value will be 10% more of your order.


7. Can I visit your factory?

Yes sure, welcome to visit our factory to get more profit.


8. How to contact with your factory?
Send inquiry in below form or send mail or call to select your way. Click here



9. Can you customize the product?
Yes, we can customize any products according to customer's requirements.

10. Which payment terms are you doing?
PayPal, West Union, T/T, (100% payment in advance.)

11. Which shipment is available?
By sea, by air ,by express or as your requirement.

12. Which country you have been exported?
We have been exported to many countries, all most all around the world, like Malaysia, Vietnam, Thailand, United States, France, Spain, Mexico, Dubai, Japan, Korea, Germany, Porland Etc.
