1.User friendly "soft touch" LED membrance control panel or touch screen is optional.
2.Strong ,firm and stable design.
3.Up&down pneumatic clamps to ensure the magazine rack position.
4.Special gas circuit design to ensure no PCB breakage.
5.L shape design, save the whole production line length.
6.With SMEMA signal.
Detail:
| Model | LF-M-BN | LF-L-BN | LF-LL-BN | LF-XL-BN |
| Dimension(L*W*H) | 1150*1150*1205mm | 1350*1350*1205mm | 1550*1550*1205mm | 1550*1780*1205mm |
| PCB size(L*W) | 50*50-330*250mm | 50*50-445*330mm | 50*50-530*390mm | 50*50-530*460mm |
| Magazine size(L*W*H) | 355*320*563mm | 460*400*563mm | 535*460*563mm | 535*530*563mm |
| Quantity of rail | Single rail | |||
| No. of magazine | Loader: upper 1, lower 2 | |||
| Conveyor belt of magazine | Plastic strips | |||
| Transport height | 900±20mm(or custimzie) | |||
| Cycle time | 6 Seconds or specity | |||
| Magazine change time | 30 Seconds or specity | |||
| Indexing pitch | 10. 20. 30. 40mm selectable | |||
| Power supply | AC 110/220V±10V, 50/60HZ | |||
| Power | Max 300VA | |||
| Air prssure | 4-6bar | |||
| Air consumption | 10itr/min max | |||
| Screen size | 7 inch | |||
| PCB thickness | Minimum 0.6mm thickness | |||
| Transport direction | L-R or R-L | |||
| CE | Yes | |||
| PLC | Yes | |||
| SMEMA | Yes | |||
| Weight | 160kg | 220kg | 280kg | 320kg |
In addition, we also sell other models of equipment for SMT production lines.
PCB buffer for AOI SPI
If you need,please contact us.
Our products are sold all over the world, you can rest assured.
