CN500 Offline AOI Optical Inspection Machine AC serve 22 inch TFT

CN500 Offline AOI Optical Inspection Machine AC serve 22 inch TFT

  • High Light

    TFT Optical Inspection Machine

    ,

    AOI Optical Inspection Machine

    ,

    TFT aoi equipment

  • Product Name
    Offline AOI Inspection Machine
  • Product Model
    CNSMT-CN500
  • Supplier
    CNSMT
  • PCB Size
    25×25mm - 340×480mm
  • Adaptive Minimum Component
    0201
  • CAMERA
    CCD Color Camera Resolution: 12/15/1
  • PER-IMAGE TIME
    <170ms
  • PASTE PRINTIG DEFECTS
    Misaligned, Overflow, Insufficient, Pasting Open, Stain
  • Lead Time
    3-5days
  • SOLDER DEFECTS
    Overflow, Insufficient, Short Solder, Stain
  • DRIVER
    AC Serve
  • Place of Origin
    China
  • Brand Name
    CNSMT
  • Certification
    CE-Automated optical inspection
  • Model Number
    CNSMT-CN500
  • Minimum Order Quantity
    1
  • Price
    1000
  • Packaging Details
    Standard woodenbox
  • Delivery Time
    3-4days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    5perday

CN500 Offline AOI Optical Inspection Machine AC serve 22 inch TFT

CN500 Offline AOI Optical Inspection Machine AC Serve 22 Inch TFT



Offline AOI CN500 Automated Optical Inspection Machine




When it comes to smart machines that will improve the SMT assembly, you can only trust CNSMT, an SMT supplier that is trusted and well recognized in Shenzhen China.



CNSMT is a leading supplier company with a 10-year strong and solid experience in helping our SMT companies around the world by providing the most advanced and smartest machines to improve production.



One of the most viable solutions in improving SMT production is the OFFLINE AOI CN500 Automated Optical Inspection Machine. An AOI machine or also referred to as Machine Vision cameras are the ones helping your assembly to achieve 100% quality every single time.



In order to avoid affecting the normal use of this OFFLINE AOI CN500 equipment due to external factors, please observe the following:


  • The use environment of this OFFLINE AOI CN500 equipment:



          The ambient temperature of the equipment is: 10~35℃, and the relative humidity is: 35~80℃



          The OFFLINE AOI CN500 equipment should be placed in a place where it will not be exposed to direct sunlight, will not condense water,                and will not splash water, oil and other chemical liquids.



  •  When the OFFLINE AOI CN500 equipment is in normal use, please reserve a certain space before and after the equipment to facilitate the maintenance of the machine and the exhaust of internal heat.



           Also do not put on objects such as hoods during the normal use of the machine, so as not to affect the heat of the device itself.





  •  When the OFFLINE AOI CN500 equipment is suspended, please keep the equipment in the following places:



           Ambient temperature: 0~40℃ Relative humidity: 35~80℃



           Places where there is no direct sunlight, no condensation, no splashing of water, oil and other chemical liquids



           In order to prevent dust, you can consider taking covering measures, such as covering the dust cover we give away.



  •  Do not subject the OFFLINE AOI CN500 equipment to impact or strong vibration, otherwise it may cause malfunctions.



  • When cutting off the power supply of the equipment, please follow the following sequence to exit/shut down the system. If you don’t execute this process, go directly



  • Cutting off or restarting the power will prevent the data from being preserved intact, and it may also cause damage to the hard disk.

CN500 Offline AOI Optical Inspection Machine AC serve 22 inch TFT 0

The correct exit steps are as follows:


Quit the application → Quit Windows → Cut off the power



  •  When the OFFLINE AOI CN500 equipment is running, please do not open the front cover of the equipment to avoid accidents.



  •  Repeated power ON (open)/OFF (cut off) will be the cause of the machine's host failure. After the power is turned off,



           Please turn on the power again after 20 seconds.



  •  In order to avoid damage to the PCB board or equipment to be tested, please use the inspection target substrate that meets the specifications and dimensions of the equipment.



Note that the requirements of this OFFLINE AOI CN500 equipment on the height of the parts on the PCB are:



The height of the front part on the test surface of the PCB board ≤ 25mm The height of the back part on the test surface of the PCB board ≤ 50mm



Points of safety


In order to use this OFFLINE AOI CN500 equipment safely, please observe the following:



⒈When adding lubricating grease for maintenance, please cut off the power supply.



⒉Please connect to the power supply according to the standard on the OFFLINE AOI CN500 equipment nameplate. If it does not match, please contact our company's after-sales service department.



⒊When installing the industrial computer of the OFFLINE AOI CN500 equipment, be sure to connect each interface firmly and not loose.



⒋When inserting the head into the test platform, please pay attention to the upper frame.



⒌When moving the industrial computer or other parts on the equipment, please cut off the power supply first, and connect the wiring that connects the removed part to the equipment Unplug.



⒍Please do not put your hands or other objects in the OFFLINE AOI CN500 equipment when it is running.



⒎Guarantee the safety grounding of the OFFLINE AOI CN500 equipment and the access of the anti-static wire. Remember that the ground wire and the anti-static wire should not be confused.



⒏When opening the front cover of the machine, please handle it gently to avoid damage to the display.



⒐Please ensure that the rear door and front flap of the device are closed when the equipment is running

CN500 Offline AOI Optical Inspection Machine AC serve 22 inch TFT 1

 Technical parameters


ITEM SPECIFICATION
INSPECTION using multiple algorithms synthetically such as WIDM,Color Image contrast technology,Color extracting technology, similarity, two-value handling technology and so on.
CAMERA CCD color camera Resolution: 12/15/1
LAMP-HOUSE Micron/dot Color CCD camera: 12/15/1 μ adjustable
  Ring RGB LED lamp-house
0201 CHIP <10ms
PER-IMAGE TIME <170ms
PASTE PRINTIG DEFECTS Misaligned, overflow, insufficient, pasting open, stain
COMPONENT DEFECTS Missing, misaligned, skewed, tombstone, billboard, overtumed, reversed polarty, wrong, damaged
SOLDER DEFECTS Overflow, insufficient, short solder, stain
ANTI STATIC MEASURES Anti static electric outlet, anti static wreath
PCB SIZE 25×25mm - 340×480mm, can make bigger size according to clients’ demands
PCB WARP TOLERANCE <2mm
COMPONENT CLEARANCE <30mm
DRIVER AC server
X,YPLATFORM ORIENTATION <15um
MOVING SPEED 700mm/s
CHARACTERISTICS WIDM, study OK template, automatically set template imaging, identify data and error numerical value
CONTROLLING library and get a inspection frame according with chip shape, aureate position, micron adjust, and easy programming
RECOGNISING SPEED 0.5s/pcs
COMPUTER CPU:Intel dual-core, MEMORY:2G, HARDDISK:500G
DISPLAY 22 inch TFT
WEIGHT 480kg
